An efficient rotary hammer for SDS-PLUS bits with an anti-vibration handle. Suitable for impact and unstressed drilling, plus chipping. Speed range of 0 – 1 100 min-1. Impact energy of 2.0 J and max. drilling capacity of 20 mm in concrete.
- Battery protection system automatically shuts off power when the battery level is low
- LED light illuminates the work site
- 3-Mode operation for "Rotation Only", "Hammering with Rotation" or "Hammering Only" for multiple applications
- Reversing switch
- Reversing switch is conveniently located
- Compact and lightweight for reduced operator fatigue
- One touch sliding chuck enables quick and easy bit changes
Technical Specification:
Nominal Battery Voltage - 18 V
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion) - Li-ion
Impact Energy - 1,9 J
Optimum Drilling Diameter Range in Concrete - 4 - 12 mm
Max. Drilling Diameter in Concrete - 20 mm
Max. Drilling Diameter in Wood - 26 mm
Max. Drilling Diameter in Steel - 13 mm
Impacts per Minute (IPM) - 0 - 4000 min⁻¹
No load speed - 0 - 1100 min⁻¹
Drilling diameter with TCT core bit - 54 mm
Tool weight with battery - 3,2 - 4,0 kg
Vibration Level, Hammer Drilling Into Concrete - 15,1 m/s²
Vibration Uncertainty (K Factor), Hammer Drilling Into Concrete - 1,5 m/s²
Vibration Level, Chiselling - 14,1 m/s²
Vibration Uncertainty (K Factor), Chiselling - 1,5 m/s²
Sound Power Level (LWA) - 99 dB(A)
Sound Pressure Level (LpA) - 91 dB(A)
Noise Uncertainty (K Factor) - 3 dB(A)
Product Dimensions (L x W x H): - 358 x 84 x 259 mm
